General characteristics

HAM bands
70cm
Frequency stability
?
Tuning steps
?
Memories
61 channels in 1 bank(s)

Receiver

RX-range
400-470 MHz
Modulations
FM
Sensitivity
0.16 µV (12 dB SINAD)
Selectivity
>12 kHz (-6 dB), <28 kHz (-60 dB)
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
430-440 MHz (General)
438-450 MHz (USA & Canada)
Modulations
FM
RF-output
High: 35 W, Medium: 10 W, Low: 5 W

Connections

Antenna
N-type
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC +/- 15%
Current drain RX
Max 600 mA
TX
Max 10 A

Physical

Dimensions (w×h×d)
140 × 40 × 160 mm (5.51 × 1.57 × 6.30 in)
Weight
1,000 gr (2.2 lbs)
Form factor
Mobile
Manufactured
Between 199x and 199x

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
3405
MPN
KENWOOD-TM-000461A

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Kenwood TM-461A. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

These estimates are based on the following prices:

Year Historic price Condition Submitted by
