New price 2003 in the US: $895.00

General characteristics

HAM bands
160m  80m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  10m
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
0.1-30 MHz
Modulations
AM   FM
Sensitivity
SSB: 0.35 µV (10 dB S+N/N @ 3 kHz bandwidth)
Selectivity
34 built-in filters with various characteristics
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
Better than 60 dB
Audio output
?

Transmitter

TX-range
10-160 m + WARC
Modulations
CW   SSB   AFSK
RF-output
100 W

Connections

Antenna
SO-239
Impedance
50 Ω
Other
-

Electrical

Power requirements
12-14V DC
Current drain RX
Max 1 A
TX
Max 20 A

Physical

Dimensions (w×h×d)
130 × 273 × 292 mm (5.12 × 10.75 × 11.50 in)
Weight
4.10 kg (9.0 lbs)
Form factor
Base Station
Manufactured
Between 1999 and 200x in USA

Other features

Usage
Amateur / Ham radio operators
Features + options
PC-controlled. IF-DSP.
Accessories
-
RigReference ID
4179
MPN
TEN-TEC-PEGASUS-(000550)
