Also known as Sommerkamp FTdx560. The is also a Yaesu FTdx-401B version which supports AM.

General characteristics

HAM bands
80m  40m  20m  15m  10m
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
10-80 m + 30 m
11 m optional
Modulations
CW   SSB
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
10-80 m + 30 m
11 m optional
Modulations
CW   SSB
RF-output
SSB: 560 W (PEP input), CW: 430 W (input)

Connections

Antenna
-
Impedance
50/100 Ω
Other
-

Electrical

Power requirements
Mains
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
400 × 160 × 350 mm (15.75 × 6.30 × 13.78 in)
Weight
18.14 kg (40.0 lbs)
Form factor
Base Station
Manufactured
Between 19xx and 19xx in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
4380
MPN
YAESU-FTDX-000401

Manuals, diagrams and brochures

Yaesu FTdx-401 Instruction manual PDF - Unknown size, submitted by RigReference
Yaesu FT-401 AM addendum PDF - Unknown size, submitted by RigReference
Schematic-1 of 5 TIFF - 95.4 kB, submitted by Michael Ince
Schematic-2 of 5 TIFF - 114.5 kB, submitted by Michael Ince
Schematic-3 of 5 TIFF - 113.8 kB, submitted by Michael Ince
Schematic-4 of 5 TIFF - 112.6 kB, submitted by Michael Ince
Schematic-5 of 5 TIFF - 114.9 kB, submitted by Michael Ince
