Price when new in 2014: 1000 GBP

General characteristics

HAM bands
160m  80m  60m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  11m (CB)  10m
Frequency stability
1 p.p.m. standard (0.1 p.p.m. optional)
Tuning steps
10 Hz
Memories
99 channels in 1 bank(s)

Receiver

RX-range
10 kHz - 30 MHz
Modulations
AM   CW   USB   LSB   FSK   Digital (other)
Sensitivity
1 µV (16 dB SINAD)
Selectivity
-6 dB: 300-2700 Hz
-60 dB: 400-3400 Hz
Filters
Additional bandwidths DSP selectable (300 / 600 / 1000 Hz)
Receiver system
DSP
IF-frequencies
?
Image rejection
?
Audio output
3W at less than 5% distortion into 4 Ohms

Transmitter

TX-range
1.6-30 MHz
Modulations
CW   USB   LSB   FSK   Digital (other)
RF-output
25 / 100 W PEP

Connections

Antenna
-
Impedance
50Ω
Other
-

Electrical

Power requirements
13.6 V DC (24 V DC optional)
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
305 × 105 × 300 mm (12.01 × 4.13 × 11.81 in)
Weight
6.00 kg (13.2 lbs)
Form factor
Mobile
Manufactured
Between 2014 and 201x

Other features

Usage
Amateur / Ham radio operators
Features + options
Remote control up to 100m
ALC
Accessories
-
RigReference ID
6077
MPN
EDDYSTONE-ORION-007000
