General characteristics

HAM bands
2m
Frequency stability
± 300 Hz / hour after warm-up
Tuning steps
Continuous
Memories
?

Receiver

RX-range
144-146 MHz
Modulations
AM   FM   CW   SSB
Sensitivity
?
Selectivity
SSB
2.4 kHz @ -3 dB, 4.5 kHz @ -60 dB
AM/FM
15 kHz @ -3 dB, 32 kHz @ -60 dB
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
70 dB
Audio output
?

Transmitter

TX-range
144-146 MHz
Modulations
AM   FM   CW   SSB
RF-output
SSB: 25 W PEP, FM: 15...25 W, AM: 25 W PEP

Connections

Antenna
SO-239
Impedance
60Ω
Other
-

Electrical

Power requirements
12 V DC
Current drain RX
2 A
TX
9 A

Physical

Dimensions (w×h×d)
256 × 105 × 273 mm (10.08 × 4.13 × 10.75 in)
Weight
5.50 kg (12.1 lbs)
Form factor
Base Station
Manufactured
Between 19xx and 19xx in West-Germany

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
6189
MPN
SEMCOSET-SELECTO

Manuals, diagrams and brochures

Semco Selecto User manual PDF - 4.11 MB, submitted by RigReference
