External video input for display on the TFT

General characteristics

HAM bands
2m  70cm
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
118-999 MHz
Modulations
AM   FM   N-FM
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
144-146 / 430-440 MHz (Europe)
Modulations
FM   N-FM
RF-output
High: 50/35 W, Mid-High: 20/20 W, Mid-Low: 10/10 W, Low: 5/5 W

Connections

Antenna
SO-239
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
?
TX
Max 12 A

Physical

Dimensions (w×h×d)
140 × 40 × 34 mm (5.51 × 1.57 × 1.34 in) Box
Weight
1 gr (0.0 oz) Box, 290 grHead
Form factor
Mobile
Manufactured
Between 2000 and 2002

Other features

Usage
Amateur / Ham radio operators
Features + options
Twin RX
Accessories
-
RigReference ID
3038
MPN
ICOM-IC-002800H

Manuals, diagrams and brochures

ICOM IC-2800H Instruction Manual.pdf PDF - Unknown size, submitted by RigReference

Upload relevant documents

Reviews & stories

Rating Title Submitted
My icom 2800h 3 years ago by Callhaay
Great radio, with some shortcomings 13 years ago by w3rxo

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used ICOM IC-2800H. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the ICOM IC-2800H is around:

  • USD 26.00 ~ USD 174.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2022 USD 175.00 Used / Good Jason McCormick
2007 USD 300.00 Used / Good w3rxo
