General characteristics

HAM bands
?
Frequency stability
?
Tuning steps
5 / 12.5 / 25 kHz
Memories
1984 channels in 62 bank(s) @ 36 channels/second

Receiver

RX-range
5-550 / 800-1300 MHz
Modulations
AM   FM   W-FM   CW   USB   LSB
Sensitivity
FM 0.45µV @ 12 dB SINAD
W-FM 1.0µV @ 12 dB SINAD
AM 1.0µV @ 10 dB S/N
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
500 mW into 8 ohms @ 10% THD

Connections

Antenna
BNC
Impedance
50Ω
Other
-

Electrical

Power requirements
11-16V DC
Current drain RX
?
TX
-

Physical

Dimensions (w×h×d)
150 × 55 × 180 mm (5.91 × 2.17 × 7.09 in)
Weight
650 gr (1.4 lbs)
Form factor
Base Station
Manufactured
Between 1985 and 199x

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
5012
MPN
AOR-AR-002500

Manuals, diagrams and brochures

AOR AR2500 Wideband Receiver Manual PDF - 572.9 kB, submitted by home video

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used AOR AR-2500. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the AOR AR-2500 is around:

  • USD 146.00 ~ USD 22.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2019 USD 162.00 Used / Good eBay
2010 USD 142.50 Used / Good eBay
