E.F. Johnson Desk Kilowatt

General characteristics

HAM bands

?

Frequency stability

?

Tuning steps

?

Memories

?

Transmitter

TX-range

3.5-30 MHz

Modulations

AM   CW   SSB

RF-output

1000 W input (AM/CW/SSB)

Connections

Antenna

-

Impedance

50/500Ω

Other

-

Electrical

Power requirements

Mains

Current drain RX

?

TX

?

Physical

Dimensions (w×h×d)

500 × 750 × 840 mm (19.69 × 29.53 × 33.07 in)

Weight

180.00 kg (397.1 lbs)

Form factor

Base Station

Manufactured

Between 1958 and 196x in USA

Other features

Usage

Amateur / Ham radio operators

Features + options

-

Accessories

-

RigReference ID

5075

MPN

E.F.-JOHNSON-DESK-KILOWATT

Manuals, diagrams and brochures

No documents available for this particular model.



Upload relevant documents

Reviews

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used E.F. Johnson Desk Kilowatt. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic price data, today's estimated value of the E.F. Johnson Desk Kilowatt in Good condition is around:

• USD 1,381 ~ USD 2,444

Price History Chart

These estimates are based on the following prices:
