Puxing PX-820

Single-band DMR Transceiver | GPS

Specs Manuals (0) Reviews (0) Prices (0) Compare

The Puxing PX-820 is a handheld transceiver. The frequency range is 400-470 MHz supporting DMR modulation. Maximum RF-output is 1 / 4 W. Audio output is 1 W @ 3% THD. Features include IP67, Digital protocol ETSI TS 102 361-1,-2,-3, GPS standard and SMS function. Memory banks: 1 with 1000 channels. Dimensions are 114 × 54 × 34 mm. Weight is 270 gr including battery.

General characteristics

HAM bands: ?
Frequency stability: ±1 p.p.m.
Tuning steps: 12.5 kHz
Memories: 1000 channels in 1 bank(s)

Receiver

RX-range: 400-470 MHz
Modulations: N-FM W-FM
Sensitivity: Analog
0.35μV / -116 dBm (20dB SINAD)
0.22μV / -120 dBm
Digital
0.3μV / -117.4 dBm (BER 5%)
0.7μV / -110 dBm (BER1%)
Selectivity: TIA603C: 65 dB @ 12.5 kHz
ETSI: 60 dB @ 12.5 kHz
Filters: ?
Receiver system: ?
IF-frequencies: ?
Image rejection: ≥60dB
Audio output: 1 W @ 3% THD

Transmitter

TX-range: 400-470 MHz
Modulations: N-FM W-FM
RF-output: 1 / 4 W

Connections

Antenna: SMA
Impedance: 50Ω
Other: -

Electrical

Power requirements: ?
Current drain RX: ?
TX: ?

Physical

Dimensions (w×h×d): 54 × 114 × 34 mm (2.13 × 4.49 × 1.34 in) not including antenna
Weight: 270 gr (9.5 oz) including battery
Form factor: Handheld
Manufactured: Between 2014 and 20xx in China

Other features

Usage: Amateur / Ham radio operators
Features + options: IP67
Digital protocol ETSI TS 102 361-1,-2,-3
GPS standard
SMS function
Accessories: -
RigReference ID: 6072
MPN: PUXING-PX-000820
