General characteristics

HAM bands
2m  70cm
Frequency stability
± 2.5 p.p.m.
Tuning steps
?
Memories
199 channels in 1 bank(s)

Receiver

RX-range
87-108 / 136-174 / 400-480 MHz
Modulations
FM   N-FM
Sensitivity
≤ 0.20 µV (12 dB SINAD)
Selectivity
?
Filters
12.5 / 25 kHz
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
500 mW

Transmitter

TX-range
136-174 / 400-480 MHz
Modulations
FM   N-FM
RF-output
1 / 5 W

Connections

Antenna
Fixed antenna
Impedance
50Ω
Other
-

Electrical

Power requirements
7.4 V DC, 1500 mAh Li-ion Battery
Current drain RX
100 mA max
TX
1 A max

Physical

Dimensions (w×h×d)
115 × 55 × 30 mm (4.53 × 2.17 × 1.18 in)
Weight
230 gr (8.1 oz)
Form factor
Handheld
Manufactured
Between 201x and 201x in China

Other features

Usage
Amateur / Ham radio operators
Features + options
"Hidden" display
PC Software Programmable
Manual Programming
Wire Copy
VOX Function
CTCSS/DCS
Monitor, Reverse Frequency
Accessories
-
RigReference ID
6146
MPN
YANTON-T-000328
