General characteristics

HAM bands
70cm
Frequency stability
± 2.5 p.p.m.
Tuning steps
?
Memories
16 channels in 1 bank(s)

Receiver

RX-range
400-480 MHz
Modulations
FM
Sensitivity
< 0.20 µV (12 dB SINAD)
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
500 mW

Transmitter

TX-range
400-480 MHz
Modulations
FM
RF-output
3 / 1 W

Connections

Antenna
SMA
Impedance
50Ω
Other
-

Electrical

Power requirements
3.7 V DC, 1000 mAh Li-ion Battery
Current drain RX
100 mA max
TX
1 A max

Physical

Dimensions (w×h×d)
85 × 38 × 25 mm (3.35 × 1.50 × 0.98 in)
Weight
105 gr (3.7 oz)
Form factor
Handheld
Manufactured
Between 201x and 201x in China

Other features

Usage
Amateur / Ham radio operators
Features + options
PC Software Programmable
VOX Function
CTCSS / DCS
Multiple colors
Accessories
-
RigReference ID
6153
MPN
YANTON-T-M000008
