DV (Digital Voice) option with EJ-47U

General characteristics

HAM bands
2m  70cm
Frequency stability
+/- 2.5 p.p.m.
Tuning steps
5 / 6.25 / 8.33 / 10 / 12.5 / 15 / 20 / 25 / 30 / 50 / 100 kHz
Memories
1000 channels in 1 bank(s)

Receiver

RX-range
108-174 / 430-480 MHz
Modulations
AM   FM   N-FM   W-FM   DV
Sensitivity
0.2 µV (12 dB SINAD)
Selectivity
FM: 15 kHz (-6 dB), 30 kHz (-50 dB)
N-FM: 9 kHz (-6 dB), 20 kHz (-50 dB)
Filters
?
Receiver system
Double conversion superheterodyne
IF-frequencies
1st IF: 21.7 MHz (VHF), 30.85 MHz (UHF)
2nd IF: 450 kHz (VHF), 455 kHz (UHF)
Image rejection
?
Audio output
2 W at 10% distortion / 8 ohms

Transmitter

TX-range
144-146 / 430-440 MHz
Modulations
FM   N-FM   DV
RF-output
5 .. 50 W

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
13.8V DC +/- 15%
Current drain RX
400-600 mA
TX
12 A max

Physical

Dimensions (w×h×d)
140 × 60 × 188 mm (5.51 × 2.36 × 7.40 in)
Weight
1.30 kg (2.9 lbs)
Form factor
Mobile
Manufactured
Between 2016 and 201x in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
EJ-47U DV option
RigReference ID
6334
MPN
ALINCO-DR-000735E

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Alinco DR-735E. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Alinco DR-735E is around:

  • USD 262.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2018 USD 320.00 New / Mint RigReference
