General characteristics

HAM bands
?
Frequency stability
± 1 p.p.m.
Tuning steps
8.33 / 25 kHz
Memories
300 channels in 15 bank(s)

Receiver

RX-range
108-137 MHz
Modulations
AM
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
Double conversion superheterodyne
IF-frequencies
46.35 MHz / 450 kHz
Image rejection
?
Audio output
?

Transmitter

TX-range
118-137 MHz
Modulations
AM
RF-output
6 W PEP, 1.8 W carrier

Connections

Antenna
BNC
Impedance
50Ω
Other
-

Electrical

Power requirements
7.2 V DC (BP-288), 11.0 V DC (External DC Jack)
Current drain RX
90-500 mA
TX
1.8 A max

Physical

Dimensions (w×h×d)
59 × 148 × 32 mm (2.32 × 5.83 × 1.26 in)
Weight
384 gr (13.6 oz) with antenna and BP-288
Form factor
Handheld
Manufactured
Between 2018 and 20xx in Japan

Other features

Usage
Air-to-air / air-to-ground communication
Features + options
Bluetooth
GPS
IP57 dust-protection and waterproof construction
2.3-inch Large High Visibility LCD
VOR Navigation Functions
Accessories
-
RigReference ID
6399
MPN
ICOM-IC-A000025NE
