True dual time slot DMR, Tier I & II, compatible with Motorola and other DMR.

General characteristics

HAM bands
2m  70cm
Frequency stability
± 2.5 p.p.m.
Tuning steps
2.5 / 5 / 6.25 / 10 / 12.5 / 25 kHz
Memories
1024 channels in 1 bank(s)

Receiver

RX-range
136-174 / 400-470 MHz
Modulations
FM   N-FM   DMR
Sensitivity
≤ 0.2 µV (12 dB SINAD)
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
1 W

Transmitter

TX-range
136-174 / 400-470 MHz
Modulations
FM   N-FM   DMR
RF-output
1 / 5 W

Connections

Antenna
SMA
Impedance
50Ω
Other
-

Electrical

Power requirements
7.4 V DC Li-ion, 1800 mAh
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
?
Weight
?
Form factor
Handheld
Manufactured
Between 2018 and 20xx in China

Other features

Usage
Amateur / Ham radio operators
Features + options
CTCSS
Accessories
-
RigReference ID
6400
MPN
BAOFENG-RD-000005R

Manuals, diagrams and brochures

Baofeng RD-5R User's Manual PDF - 2.58 MB, submitted by RigReference

Upload relevant documents

Reviews & stories

Rating Title Submitted
BAOFENG 5 years ago by vk4wir

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Baofeng RD-5R. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Baofeng RD-5R is around:

  • USD 72.00 ~ USD 61.00
  • CAD 61.00
  • AUD 22.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2019 AUD 25.00 Used / Good Brett Robson
2019 USD 80.00 New / Mint mautas
2018 USD 75.00 New / Mint RigReference
2018 CAD 75.00 New / Mint Mike Caissie
