General characteristics

HAM bands
?
Frequency stability
?
Tuning steps
?
Memories
2000 channels in 1 bank(s)

Receiver

RX-range
0.1-2150 MHz
Modulations
AM   FM   W-FM   CW   SSB
Sensitivity
AM (10 dB S/N)
0.1-5 MHz: 1.5 µV
5-900 MHz: 1 µV
FM (12 dB SINAD)
5-900 MHz: 0.5 µV
900-2150 MHz: 2 µV
W-FM (12 dB SINAD)
5-900 MHz: 2 µV
900-2150 MHz: 4 µV
SSB/CW (10 dB S/N)
0.1-5 MHz: 0.6 µV
5-900 MHz: 0.5 µV
900-2150 MHz: 1 µV
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Connections

Antenna
BNC
Impedance
50 Ω
Other
-

Electrical

Power requirements
4.8-7.2V DC or 10-16V DC external
Current drain RX
50-150 mA
TX
-

Physical

Dimensions (w×h×d)
57 × 150 × 28 mm (2.24 × 5.91 × 1.10 in)
Weight
320 gr (11.3 oz)
Form factor
Handheld
Manufactured
Between 19xx and 19xx in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
CTCSS/PL
Accessories
-
RigReference ID
2297
MPN
ALINCO-DJ-X000020
