General characteristics

HAM bands
?
Frequency stability
?
Tuning steps
?
Memories
1000 channels in 1 bank(s)

Receiver

RX-range
0.1-1300 MHz
Modulations
AM   FM   W-FM
Sensitivity
AM (10 dB S/N)
0.1-50 MHz: 0.89 µV
50-1300 MHz: 0.45 µV
FM (12 dB SINAD)
30-470 MHz: 0.17 µV
470-1300 MHz: 0.5 µV
W-FM (12 dB SINAD)
76-470 MHz: 0.5 µV
470-1300 MHz: 0.7 µV
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Connections

Antenna
SMA
Impedance
50 Ω
Other
-

Electrical

Power requirements
2.4-3V DC (battery) or 5.4-6V DC external
Current drain RX
26-140 mA
TX
-

Physical

Dimensions (w×h×d)
58 × 99 × 32 mm (2.28 × 3.90 × 1.26 in)
Weight
220 gr (7.8 oz) with EBP57
Form factor
Handheld
Manufactured
Between 2007 and 200x

Other features

Usage
Amateur / Ham radio operators
Features + options
CTCSS. Bug detector. Alpha tags. Digital recording/playback
Accessories
-
RigReference ID
2305
MPN
ALINCO-DJ-X000008
