General characteristics

HAM bands
2m
Frequency stability
?
Tuning steps
?
Memories
20 channels in 1 bank(s)

Receiver

RX-range
144-146 MHz
Modulations
FM
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
144-146 MHz
Modulations
FM
RF-output
High: 50 W, Low: 5 W

Connections

Antenna
-
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
Max 800 mA
TX
Max 10.5 A

Physical

Dimensions (w×h×d)
140 × 40 × 155 mm (5.51 × 1.57 × 6.10 in)
Weight
860 gr (1.9 lbs)
Form factor
Mobile
Manufactured
Between 19xx and 19xx

Other features

Usage
Amateur / Ham radio operators
Features + options
CTCSS
Accessories
-
RigReference ID
2311
MPN
ALINCO-DR-000130

Manuals, diagrams and brochures

Alinco DR-130/330/430 Instruction manual PDF - Unknown size, submitted by RigReference

Upload relevant documents

Reviews & stories

Rating Title Submitted
Powerful Transceiver For Less Budget 11 years ago by binonie

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Alinco DR-130. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Alinco DR-130 is around:

  • USD 49.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2021 USD 50.00 Used / Good Dave
