General characteristics

HAM bands
80m  40m  20m  15m  10m
Frequency stability
less than 500 Hz variation
Tuning steps
Continuous
Memories
None

Transmitter

TX-range
80-10 m
3.5-4 / 7-7.5 / 14-14.5 / 21-21.5 / 28-29 / 29-30 MHz
Modulations
AM   CW
RF-output
50 W

Connections

Antenna
SO-239
Impedance
40-1000Ω
Other
-

Electrical

Power requirements
Mains (110 / 125 / 140 / 160 / 220 / 280 V AC, 50-60 Hz)
Current drain RX
-
TX
195 VA max

Physical

Dimensions (w×h×d)
520 × 260 × 250 mm (20.47 × 10.24 × 9.84 in)
Weight
?
Form factor
Base Station
Manufactured
Between 1964 and 1966 in Italy

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
2678
MPN
GELOSO-G000004/223

Manuals, diagrams and brochures

Geloso G4/223 Instruction Manual (En/It) PDF - 2.44 MB, submitted by RigReference
