General characteristics

HAM bands
2m
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
144-146 MHz
Modulations
FM
Sensitivity
0.4 µV (20 dB S/N)
Selectivity
10 kHz (-6 dB)
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
144-146 MHz
Modulations
FM
RF-output
0.5-10 W

Connections

Antenna
SO-239
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC or mains
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
230 × 111 × 260 mm (9.06 × 4.37 × 10.24 in)
Weight
7.20 kg (15.9 lbs)
Form factor
Unknown
Manufactured
Between 19xx and 19xx in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
Diode matrix programmable
Accessories
-
RigReference ID
2987
MPN
ICOM-IC-000021A

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Rating Title Submitted
Icom IC21A 1990-ish 6 years ago by tadd

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used ICOM IC-21A. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the ICOM IC-21A is around:

  • USD 0.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
1990 USD 50.00 Used / Good tadd
