General characteristics

HAM bands
2m
Frequency stability
?
Tuning steps
5 kHz
Memories
?

Receiver

RX-range
144-146 MHz
Modulations
FM
Sensitivity
?
Selectivity
15 kHz (-6 dB), 30 kHz (-60 dB)
Filters
?
Receiver system
Double conversion superheterodyne
IF-frequencies
1st: 10.695 MHz
2nd: 455 KHz
Image rejection
>60 dB
Audio output
?

Transmitter

TX-range
144-146 MHz
Modulations
FM
RF-output
High: 1.5 W @ 8.4 VDC, Low: 150 mW @ 8.4 VDC

Connections

Antenna
BNC
Impedance
50 Ω
Other
-

Electrical

Power requirements
8-10.8V DC
Current drain RX
20-130 mA
TX
220-550 mA

Physical

Dimensions (w×h×d)
65 × 167 × 35 mm (2.56 × 6.57 × 1.38 in)
Weight
450 gr (15.9 oz) battery and antenna included
Form factor
Handheld
Manufactured
Between 1980 and 1990 in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
1750 Hz tone burst
Accessories
-
RigReference ID
3049
MPN
ICOM-IC-000002E

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used ICOM IC-2E. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the ICOM IC-2E is around:

  • EUR 49.00 ~ EUR 0.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2015 EUR 100.00 Used / Good Ruediger
1991 EUR 50.00 Used / Good Jens
