General characteristics

HAM bands
2m  70cm
Frequency stability
?
Tuning steps
?
Memories
36 channels in 1 bank(s)

Receiver

RX-range
144-146/430-440 MHz (Europe)
140-150/440-450 MHz (USA)
Modulations
FM
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
144-146/430-440 MHz (Europe)
140-150/440-450 MHz (USA)
Modulations
FM
RF-output
High: 45/35 W, Low 2: 10/10 W, Low 1: 5/5 W

Connections

Antenna
SO-239
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
0.8-1.2 A
TX
Max 10 A

Physical

Dimensions (w×h×d)
140 × 40 × 195 mm (5.51 × 1.57 × 7.68 in)
Weight
1.40 kg (3.1 lbs)
Form factor
Mobile
Manufactured
Between 19xx and 19xx

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
3069
MPN
ICOM-IC-003220H
