ICOM IC-575A

Desktop HF/VHF Transceiver

Specs Manuals (0) Reviews (0) Prices (1) Compare

The ICOM IC-575A is a desktop HF/VHF transceiver. It covers 26-56 MHz in receive and 28-29.7 / 50-54 MHz in transmit. The RF output is AM: 1-4 W, FM/SSB/CW: 1-10 W. It features 1 memory bank with 99 channels. Power requirements are 13.8V DC or mains. Dimensions are 95 × 241 × 239 mm. The transceiver weighs 6.1 kg. Current drain is 1.4-1.6 A in receive and a maximum of 5.2 A in transmit.

General characteristics

HAM bands: 6m
Frequency stability: ?
Tuning steps: ?
Memories: 99 channels in 1 bank(s)

Receiver

RX-range: 26-56 MHz
Modulations: AM FM CW SSB
Sensitivity: AM: <1 µV (10 dB S/N)
FM: <0.25 µV (12 dB SINAD)
SSB/CW: <0.13 µV (10 dB S/N)
Selectivity: AM: 6 kHz (-6 dB), 15 kHz (-60 dB)
FM: 15 kHz (-6 dB), 30 kHz (-60 dB)
SSB/CW: 2.3 kHz (-6 dB), 4 kHz (-60 dB)
Filters: ?
Receiver system: ?
IF-frequencies: ?
Image rejection: ?
Audio output: ?

Transmitter

TX-range: 28-29.7 / 50-54 MHz
Modulations: AM FM CW SSB
RF-output: AM: 1-4 W, FM/SSB/CW: 1-10 W

Connections

Antenna: SO-239
Impedance: 50 Ω
Other: -

Electrical

Power requirements: 13.8V DC or mains
Current drain RX: 1.4-1.6 A
TX: Max 5.2 A

Physical

Dimensions (w×h×d): 241 × 95 × 239 mm (9.49 × 3.74 × 9.41 in)
Weight: 6.10 kg (13.5 lbs)
Form factor: Base Station
Manufactured: Between 1988 and 199x in Japan

Other features

Usage: Amateur / Ham radio operators
Features + options: -
Accessories: -
RigReference ID: 3121
MPN: ICOM-IC-000575A

We do our best to be accurate, but if you've spotted something wrong or incomplete, please let us know!

Manuals, diagrams and brochures

: No documents available for this particular model.

: Upload relevant documents

Reviews

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used ICOM IC-575A. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic price data, today's estimated value of the ICOM IC-575A in Good condition is around:

USD 169

Price History Chart

These estimates are based on the following prices:

Year	Historic price	Condition	Submitted by
2019	USD 100.00	Used / Okay	Jim M.
