General characteristics

HAM bands
160m  80m  40m  20m  15m  10m
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
10-160 m
Modulations
CW   SSB   RTTY
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
10-160 m
Modulations
CW   SSB   RTTY
RF-output
Max 100 W

Connections

Antenna
SO-239
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
?
TX
Max 18 A

Physical

Dimensions (w×h×d)
241 × 111 × 311 mm (9.49 × 4.37 × 12.24 in)
Weight
7.30 kg (16.1 lbs)
Form factor
Base Station
Manufactured
Between 1978 and 19xx in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
3127
MPN
ICOM-IC-000701

Manuals, diagrams and brochures

IC-701 User manual PDF - 6.03 MB, submitted by Ian
A Unit H JPEG - 2.61 MB, submitted by Ian
ALC Unit H JPEG - 667.1 kB, submitted by Ian
B Unit H JPEG - 5.15 MB, submitted by Ian
Driver Unit H JPEG - 6.35 MB, submitted by Ian
EF JPEG - 900.3 kB, submitted by Ian
Filter Unit H JPEG - 1.13 MB, submitted by Ian
IC-701/1 JPEG - 5.23 MB, submitted by Ian
IC-701/2 JPEG - 5.80 MB, submitted by Ian
IC-701/3 JPEG - 6.12 MB, submitted by Ian
IC-701 Back 1 JPEG - 4.82 MB, submitted by Ian
IC-701 Back 2 JPEG - 4.74 MB, submitted by Ian
LED Unit JPEG - 535.3 kB, submitted by Ian
Matrix Board JPEG - 489.5 kB, submitted by Ian
Schematic Name Page JPEG - 532.9 kB, submitted by Ian
PA Unit H JPEG - 1.68 MB, submitted by Ian
PLL Unit JPEG - 1.79 MB, submitted by Ian
Relay Switch Unit H JPEG - 641.9 kB, submitted by Ian
RF Unit H JPEG - 2.46 MB, submitted by Ian

Upload relevant documents

Reviews & stories

Rating Title Submitted
Great 1st HF rig 9 years ago by davefer_work

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used ICOM IC-701. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the ICOM IC-701 is around:

  • USD 139.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2014 USD 350.00 Used / Good davefer_work
