General characteristics

HAM bands
160m  80m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  6m  10m
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
0.5-30 / 46.2-61.1 MHz
Modulations
AM   FM   CW   SSB
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
10-160 m + WARC / 50-54 MHz
Modulations
AM   FM   CW   SSB
RF-output
10-100 / 1-10 W (AM 10-40/1-4 W)

Connections

Antenna
SO-239
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
?
TX
Max 20 A

Physical

Dimensions (w×h×d)
241 × 94 × 239 mm (9.49 × 3.70 × 9.41 in)
Weight
4.60 kg (10.1 lbs)
Form factor
Base Station
Manufactured
Between 1992 and 199x

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
3142
MPN
ICOM-IC-000729

Manuals, diagrams and brochures

ICOM IC-729 Service Manual PDF - 13.81 MB, submitted by Robert E Sturcke

Upload relevant documents

Reviews & stories

Rating Title Submitted
Easy to use rig with added features 7 years ago by ae2dx

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used ICOM IC-729. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the ICOM IC-729 is around:

  • USD 405.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2019 USD 450.00 Used / Mint Robert E Sturcke
