The ICOM ID-91 is similar to the IC-91 with the addition of D-Star capabilities.
General characteristics
- HAM bands
- 2m 70cm
- Frequency stability
- ?
- Tuning steps
- 5 / 6.25 / 8.33 / 9 / 10 / 12.5 / 15 / 20 / 25 / 30 / 50 / 100 / 125 / 200 kHz
- Memories
- 1304 channels in 1 bank(s)
Receiver
- RX-range
- 0.5-999 MHz
- Modulations
- AM FM N-FM GMSK
- Sensitivity
- ?
- Selectivity
- ?
- Filters
- ?
- Receiver system
- ?
- IF-frequencies
- ?
- Image rejection
- ?
- Audio output
- ?
Transmitter
- TX-range
- 144-146 / 430-440 MHz (Asia)
- Modulations
- FM N-FM
- RF-output
- High: 5 / 5 W, Low: 500 / 500 mW
Connections
- Antenna
- SMA
- Impedance
- 50 Ω
- Other
- -
Electrical
- Power requirements
- 7.4V DC (battery pack) 10-16V DC (external)
- Current drain RX
- ?
- TX
- 0.8-2.1 A
Physical
- Dimensions (w×h×d)
- 58 × 103 × 24 mm (2.28 × 4.06 × 0.94 in)
- Weight
- 300 gr (10.6 oz) without batteries and antenna
- Form factor
- Handheld
- Manufactured
- Between 2006 and 200x
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- Alpha tags. CTCSS and DTCS. Twin RX
- Accessories
- -
- RigReference ID
- 3276
- MPN
- ICOM-ID-000091
Manuals, diagrams and brochures
-
No documents available for this particular model.
