The Lafayette HE-10 is a very rare short-wave receiver. It looks similar to the Hallicrafters S-38, but is in fact very different.

The receiver was also sold as the Lafayette KT-200 in kit form.

General characteristics

HAM bands
?
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
0.54-30 MHz in 4 bands
Modulations
AM   CW
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
9 tubes
IF-frequencies
455 kHz
Image rejection
?
Audio output
1.5 W, external speaker required

Connections

Antenna
Clamps / screws
Impedance
~500Ω
Other
-

Electrical

Power requirements
Mains
Current drain RX
?
TX
-

Physical

Dimensions (w×h×d)
390 × 210 × 240 mm (15.35 × 8.27 × 9.45 in)
Weight
11.00 kg (24.3 lbs)
Form factor
Base Station
Manufactured
Between 1959 and 1963 in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
ANL
AVC
BFO
IF Gain control
Receive/Standby switch
Accessories
-
RigReference ID
3545
MPN
LAFAYETTE-HE-000010-(KT-200)
