Removed from the US market only weeks after being introduced. Appearantly, it was to easy to modify for illegal use.

General characteristics

HAM bands
2m
Frequency stability
?
Tuning steps
5 kHz
Memories
?

Receiver

RX-range
144-148 MHz / 438-450 MHz
Modulations
FM
Sensitivity
VHF: 0.16 µV (12 dB SINAD)
UHF: 0.18 µV (12 dB SINAD)
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
144-148 MHz / 438-450 MHz
Modulations
FM
RF-output
High: 2-5/2-5 W (Depending on voltage), Medium: 2/1.8 W, Low: 0.35/0.35 W

Connections

Antenna
BNC
Impedance
50 Ω
Other
-

Electrical

Power requirements
6-16V DC
Current drain RX
20-250 mA
TX
0.5-1.5 A

Physical

Dimensions (w×h×d)
61 × 189 × 43 mm (2.40 × 7.44 × 1.69 in)
Weight
380 gr (13.4 oz)
Form factor
Handheld
Manufactured
Between 1997 and 1997

Other features

Usage
Amateur / Ham radio operators
Features + options
CTCSS and DTMF
Twin RX
Accessories
-
RigReference ID
3930
MPN
RADIOSHACK-/-REALISTIC-HTX-000204
