General characteristics

HAM bands
80m  40m  20m  15m  10m
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
10-80 m
Modulations
AM   CW   SSB
Sensitivity
0.3 µV S/N 10 dB
Selectivity
SSB, 2~4 kHz @ 6db
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
3 W at 4 ohms

Transmitter

TX-range
10-80 m
Modulations
AM   CW   SSB
RF-output
100 W

Connections

Antenna
SO-239
Impedance
50 Ω
Other
-

Electrical

Power requirements
Mains
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
340 × 153 × 285 mm (13.39 × 6.02 × 11.22 in)
Weight
14.00 kg (30.9 lbs)
Form factor
Base Station
Manufactured
Between 1973 and 19xx

Other features

Usage
Amateur / Ham radio operators
Features + options
Noise blanker
VOX
+/- 5 kHz clarifier
Accessories
-
RigReference ID
4248
MPN
YAESU-FT-000201S
