Analog readout

General characteristics

HAM bands
160m  80m  40m  20m  15m  10m
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
10-160 m + CB and WWV
Modulations
AM   CW   SSB   FSK
Sensitivity
0.25 µV (10 dB S/N)
Selectivity
SSB: 2.4 kHz (-6 dB), 4 kHz (-60 dB)
CW/FSK: 0.6 kHz (-6 dB), 4 kHz (-60 dB)
AM: 6 kHz (-6 dB), 12 kHz (-60 dB)
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
Better than 60 dB (15-160 m) Better than 50 dB (10 m)
Audio output
?

Transmitter

TX-range
10-160 m
Modulations
AM   CW   SSB   FSK
RF-output
SSB: 200 W (PEP input), CW: 200 W (input), AM/FSK: 50 W (input)

Connections

Antenna
SO-239
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.5V DC
Current drain RX
Max 1.1 A
TX
Max 21 A

Physical

Dimensions (w×h×d)
280 × 125 × 370 mm (11.02 × 4.92 × 14.57 in)
Weight
9.00 kg (19.9 lbs)
Form factor
Base Station
Manufactured
Between 197x and 19xx

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
4283
MPN
YAESU-FT-000301

Manuals, diagrams and brochures

Yaesu FT-301 Instruction Manual PDF - Unknown size, submitted by RigReference
