General characteristics

HAM bands
11m (CB)
Frequency stability
?
Tuning steps
Channelized
Memories
240 channels in 1 bank(s)

Receiver

RX-range
26.865-27.265 MHz
Modulations
AM   FM   USB   LSB
Sensitivity
0.5 µV (10 dB S+N/N
Selectivity
3 kHz @ -6 dB
Filters
?
Receiver system
Double conversion superheterodyne
IF-frequencies
10.7 MHz
455 kHz
Image rejection
50 dB
Audio output
3 W / 8 Ohm

Transmitter

TX-range
26.865-27.265 MHz
Modulations
AM   FM   USB   LSB
RF-output
4.8 W

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
13.8 V DC
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
185 × 63 × 247 mm (7.28 × 2.48 × 9.72 in)
Weight
2.00 kg (4.4 lbs)
Form factor
Mobile
Manufactured
Between 199x and 199x

Other features

Usage
Citizen Band (27Mc)
Features + options
ANL
NB
Clarifier
Accessories
-
RigReference ID
4703
MPN
ALAN-000088S

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Alan 88S. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

These estimates are based on the following prices:

Year Historic price Condition Submitted by
