General characteristics

HAM bands
160m  80m  60m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  11m (CB)  10m
Frequency stability
?
Tuning steps
?
Memories
?

Transmitter

TX-range
80-10 m
Modulations
All mode
RF-output
SSB: 600 W PEP, CW/FM: 500 W, AM: 300 W

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
?
TX
70 A max

Physical

Dimensions (w×h×d)
300 × 100 × 342 mm (11.81 × 3.94 × 13.46 in)
Weight
8.00 kg (17.7 lbs)
Form factor
Base Station
Manufactured
Between 20xx and 20xx

Other features

Usage
Amateur / Ham radio operators
Features + options
Input power: 10W / 100W switchable manual
Built-in SWR / Power meter
Accessories
-
RigReference ID
5291
MPN
TOKYO-HY-POWER-HL-000700B

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Tokyo Hy-Power HL-700B. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Tokyo Hy-Power HL-700B is around:

  • EUR 0.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2021 EUR 1.00 New / Mint RadioByBoy
