General characteristics

HAM bands
2m  70cm
Frequency stability
± 2.5 p.p.m.
Tuning steps
25 / 20 / 12.5 kHz
Memories
8 channels in 1 bank(s)

Receiver

RX-range
136-174 MHz
400-470 / 450-500 / 350-400 MHz (depending on version)
Modulations
FM
Sensitivity
0.28 / 0.33 / 0.35 μV
Selectivity
75 / 70 / 65 dB
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
5W (less than 5% distortion) 3W (less than 3% distortion)

Transmitter

TX-range
136-174 MHz
400-470 / 450-500 / 350-400 MHz (depending on version)
Modulations
FM
RF-output
5 / 25 W

Connections

Antenna
-
Impedance
50Ω
Other
-

Electrical

Power requirements
13.6V DC ±15%
Current drain RX
2 A max
TX
8 A max

Physical

Dimensions (w×h×d)
152 × 43 × 125 mm (5.98 × 1.69 × 4.92 in)
Weight
1,000 gr (2.2 lbs)
Form factor
Mobile
Manufactured
Between 201x and 201x in China

Other features

Usage
Commercial / Land mobile communication
Features + options
-
Accessories
-
RigReference ID
5635
MPN
HYTERA-TM-000600
