Tecsun HAM-2000

General characteristics

HAM bands

?

Frequency stability

?

Tuning steps

?

Memories

70 channels in 1 bank(s)

Receiver

RX-range

0.1-30 MHz (AM, SSB)
87-108 MHz (FM)
118-137 MHz (AM)

Modulations

AM   FM   SSB

Sensitivity

AM 0.1-30 MHz: 2 µV (10 dB S+N/N)
AM 118-137 MHz: 4 µV (1000 Hz, 30% mod)
W-FM: 4 µV (20 dB S/N, mono)
SSB: 0.5 µV (10 dB S+N/N)

Selectivity

AM/SSB (BW=6 kHz)
>6 kHz (-6 dB), <12 kHz (-60 dB)
AM/SSB (BW=4 kHz)
>4 kHz (-6 dB), <9 kHz (-60 dB)
AM/SSB (BW=2.3 kHz)
>2.3 kHz (-6 dB), <5 kHz (-60 dB)

Filters

?

Receiver system

PLL

IF-frequencies

?

Image rejection

>60 dB (0.1-30 / 118-137 MHz) >50 dB (87-108 MHz)

Audio output

Internal speaker / headphones

Connections

Antenna

F-type + Built-in telescopic

Impedance

50Ω

Other

-

Electrical

Power requirements

9V DC (Mains or 6×D cells)

Current drain RX

510-830 mA

TX

-

Physical

Dimensions (w×h×d)

506 × 235 × 226 mm (19.92 × 9.25 × 8.90 in)

Weight

6.60 kg (14.6 lbs) with power supply

Form factor

Portable

Manufactured

Between 200x and 200x in China

Other features

Usage

Amateur / Ham radio operators

Features + options

ANL
Dual clock

Accessories

-

RigReference ID

5650

MPN

TECSUN-HAM-002000

Manuals, diagrams and brochures

No documents available for this particular model.



Upload relevant documents

Reviews

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Tecsun HAM-2000. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on similar Receiver equipment, the estimated value of the Tecsun HAM-2000 is around:

• USD 140 ~ USD 260

This estimate is based on similar equipment and may not reflect the exact value of this model.

These estimates are based on the following prices:
