General characteristics
- HAM bands
- 2m
- Frequency stability
- ?
- Tuning steps
- 5 kHz
- Memories
- ?
Receiver
- RX-range
- 144-146 MHz
- Modulations
- FM
- Sensitivity
- ?
- Selectivity
- ?
- Filters
- ?
- Receiver system
- Double conversion superheterodyne
- IF-frequencies
- 10.695 MHz / 455 kHz
- Image rejection
- ?
- Audio output
- 500 mW
Transmitter
- TX-range
- 144-146 MHz
- Modulations
- FM
- RF-output
- 150 mW / 1.5 W
Connections
- Antenna
- BNC
- Impedance
- 50Ω
- Other
- -
Electrical
- Power requirements
- 5.5-11 V DC
- Current drain RX
- 150 mA
- TX
- 550 mA max
Physical
- Dimensions (w×h×d)
- 60 × 158 × 38 mm (2.36 × 6.22 × 1.50 in) with BA-2
- Weight
- 370 gr (13.1 oz) with BA-2
- Form factor
- Handheld
- Manufactured
- Between 198x and 198x
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- -
- Accessories
- -
- RigReference ID
- 5896
- MPN
- DAIWA-MT-000020
Manuals, diagrams and brochures
-
No documents available for this particular model.
- Upload relevant documents
New and second-hand prices
Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Daiwa MT-20. Just bought or sold this model? Let us know what you traded it for and help other ham operators!
Based on historic data, today's second-hand price of the Daiwa MT-20 is around:
- USD 1.00
These estimates are based on the following prices:
