General characteristics

HAM bands
40m  30m (WARC)  20m  6m
Frequency stability
?
Tuning steps
10 / 100 Hz, 1 / 100 kHz
Memories
?

Receiver

RX-range
5-16 MHz
Modulations
CW   USB
Sensitivity
?
Selectivity
4 crystal filter, SSB bandwidth of about 2.2-1.6KHz four selectable bandwidth, CW bandwidth of about 900-400Hz four selectable bandwidth
Filters
?
Receiver system
?
IF-frequencies
400 Hz - 3 kHz
Image rejection
?
Audio output
8 ohm load about 0.1W

Transmitter

TX-range
7.0-7.3 / 10.1-10.15 / 14.0-14.35 MHz
20 / 30 / 40 m
Modulations
CW
RF-output
4 W max @ 13.8 V

Connections

Antenna
BNC
Impedance
50Ω
Other
-

Electrical

Power requirements
8 × AA batteries or 9-14 V DC
Current drain RX
55 mA
TX
550-950 mA

Physical

Dimensions (w×h×d)
140 × 95 × 35 mm (5.51 × 3.74 × 1.38 in)
Weight
500 gr (1.1 lbs)
Form factor
Handheld
Manufactured
Between 201x and 201x

Other features

Usage
Amateur / Ham radio operators
Features + options
DDS circuit with 50MHz reference frequency
1602 LCD
Accessories
-
RigReference ID
6029
MPN
YOUKITS-HB-000001A
