General characteristics

HAM bands
2m
Frequency stability
± 2.5 p.p.m.
Tuning steps
2.5 / 5 / 6.25 / 8.33 / 10 / 12.5 / 15 / 25 / 30 / 50 kHz
Memories
200 channels in 1 bank(s)

Receiver

RX-range
136-174 MHz
Modulations
FM   N-FM   GMSK
Sensitivity
FM: 0.25 µV
FM-N: 0.35 µV
Selectivity
?
Filters
12.5 / 20 / 25 kHz
Receiver system
?
IF-frequencies
?
Image rejection
≥ 70 dB
Audio output
> 2 W @ 10%

Transmitter

TX-range
136-174 MHz
Modulations
FM   N-FM   GMSK
RF-output
60/25/10 W

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
13.8V DC ±15%
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
145 × 47 × 190 mm (5.71 × 1.85 × 7.48 in)
Weight
1.20 kg (2.6 lbs)
Form factor
Mobile
Manufactured
Between 2014 and 20xx

Other features

Usage
Amateur / Ham radio operators
Features + options
Carrier/CTCSS/DCS/5Tone/2Tone/DTMF
Accessories
-
RigReference ID
6090
MPN
ALINCO-DR-000138

Manuals, diagrams and brochures

Alinco DR-138/438 User Manual PDF - Unknown size, submitted by RigReference

Upload relevant documents

Reviews & stories

Rating Title Submitted
Tx/rx meter: 3 years ago by louipcruz

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Alinco DR-138. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Alinco DR-138 is around:

  • USD 147.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2021 USD 150.00 New / Mint louipcruz
