General characteristics

HAM bands
70cm
Frequency stability
± 2.5 p.p.m.
Tuning steps
?
Memories
129 channels in 1 bank(s)

Receiver

RX-range
400-480 MHz
Modulations
FM
Sensitivity
≤ 0.20 µV (12 dB SINAD)
Selectivity
?
Filters
12.5 / 25 kHz
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
500 mW

Transmitter

TX-range
400-480 MHz
Modulations
FM
RF-output
5 W

Connections

Antenna
SMA
Impedance
50Ω
Other
-

Electrical

Power requirements
3.7 V DC, 1200 mAh Li-ion Battery
Current drain RX
100 mA max
TX
1 A max

Physical

Dimensions (w×h×d)
122 × 60 × 38 mm (4.80 × 2.36 × 1.50 in)
Weight
232 gr (8.2 oz)
Form factor
Handheld
Manufactured
Between 2017 and 201x in China

Other features

Usage
Amateur / Ham radio operators
Features + options
PC Software Programmable
Manual Programming
Wire Copy
VOX Function
CTCSS/DCS
Monitor, Reverse Frequency
Accessories
-
RigReference ID
6338
MPN
YANTON-T-000288

Manuals, diagrams and brochures

No documents available for this particular model.
