General characteristics

HAM bands
?
Frequency stability
?
Tuning steps
25 kHz
Memories
55 channels in 1 bank(s)

Receiver

RX-range
156.300-162.025 MHz
Modulations
FM
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
Double conversion superheterodyne
IF-frequencies
21.4 MHz / 455 kHz
Image rejection
?
Audio output
?

Transmitter

TX-range
156.300-162.025 MHz
Modulations
FM
RF-output
1/25 W

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
12 V DC
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
180 × 50 × 230 mm (7.09 × 1.97 × 9.06 in)
Weight
1.68 kg (3.7 lbs)
Form factor
Mobile
Manufactured
Between 19xx and 19xx

Other features

Usage
Marine / Navy
Features + options
-
Accessories
-
RigReference ID
6595
MPN
PRESIDENT-MC-006800-DSC
