The MAT-TUNER mAT-1500ProII is a versatile automatic antenna tuner designed for transmitters and linear amplifiers with up to 1500 watts (SSB) or 800 watts in digital mode. It works in the frequency range from 1.8 to 30 MHz and matches almost any coax-fed antenna system – be it a dipole, a vertical or a yagi – even with complex impedances.
Frequency range: 1.8–30 MHz
Max. power: 1500 W (SSB), 800 W (digital)
Tuning: 8 sec (full), 0.1 sec (memory)
General characteristics
- HAM bands
- 160m 80m 60m 40m 30m (WARC) 20m 17m (WARC) 15m 12m (WARC) 11m (CB) 10m
- Frequency stability
- ?
- Tuning steps
- ?
- Memories
- 16000 channels in 1 bank(s)
Connections
- Antenna
- SO-239
- Impedance
- ?
- Other
- -
Electrical
- Power requirements
- 12-14 V DC
- Current drain RX
- 2 A
- TX
- ?
Physical
- Dimensions (w×h×d)
- 290 × 78 × 243 mm (11.42 × 3.07 × 9.57 in)
- Weight
- 3.50 kg (7.7 lbs)
- Form factor
- Base Station
- Manufactured
- Between 2025 and 20xx in China
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- -
- Accessories
- -
- RigReference ID
- 6651
- MPN
- MAT-TUNER-MAT-001500PROII
Manuals, diagrams and brochures
-
No documents available for this particular model.
- Upload relevant documents
New and second-hand prices
Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used MAT-TUNER mAT-1500ProII. Just bought or sold this model? Let us know what you traded it for and help other ham operators!
Based on historic data, today's second-hand price of the MAT-TUNER mAT-1500ProII is around:
- EUR 634.00
- USD 923.00
These estimates are based on the following prices:
