General characteristics

HAM bands
70cm
Frequency stability
± 5 p.p.m.
Tuning steps
?
Memories
40 channels in 1 bank(s)

Receiver

RX-range
430-440 MHz
Modulations
FM
Sensitivity
?
Selectivity
6 kHz (-6 dB), 13 kHz (-60 dB)
Filters
?
Receiver system
Double conversion superheterodyne
IF-frequencies
1st: 45.1 MHz
2nd: 455 kHz
Image rejection
> 60 dB
Audio output
> 200 mW (8Ω)

Transmitter

TX-range
430-440 MHz
Modulations
FM
RF-output
High: 4 W, Low: ? mW

Connections

Antenna
-
Impedance
50 Ω
Other
-

Electrical

Power requirements
7-16V DC
Current drain RX
20-50 mA
TX
Max 1.4 A

Physical

Dimensions (w×h×d)
56 × 124 × 37 mm (2.20 × 4.88 × 1.46 in)
Weight
300 gr (10.6 oz) with EBP-50N
Form factor
Handheld
Manufactured
Between 200x and 200x in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
2251
MPN
ALINCO-DJ-000493J

Manuals, diagrams and brochures

Alinco DJ-193/493 Instruction manual PDF - Unknown size, submitted by RigReference
Alinco DJ-493/496 Service manuals Addendum.zip ZIP - Unknown size, submitted by RigReference
