General characteristics

HAM bands
2m
Frequency stability
?
Tuning steps
?
Memories
2 channels in 1 bank(s)

Receiver

RX-range
144-148 MHz
Modulations
FM   CW   SSB
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
144-148 MHz
Modulations
FM   CW   SSB
RF-output
High: 10 W, Low: 1 W

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
0.4-0.8 A
TX
Max 3 A

Physical

Dimensions (w×h×d)
163 × 73 × 260 mm (6.42 × 2.87 × 10.24 in)
Weight
2.60 kg (5.7 lbs)
Form factor
Mobile
Manufactured
Between 19xx and 19xx

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
2665
MPN
FDK-MULTI-000750

Manuals, diagrams and brochures

FDK Multi-750 IM PDF - 2.65 MB, submitted by Berend
FDK Multi-750 SM PDF - 1.76 MB, submitted by Berend

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used FDK Multi-750. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

These estimates are based on the following prices:

Year Historic price Condition Submitted by

Login or Register to submit prices

Links & tools
