General characteristics

HAM bands
80m  40m  20m  15m  10m
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
10-80 m
Modulations
CW   SSB
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
10-80 m
Modulations
CW   SSB
RF-output
100 W (80 W on 10 m)

Connections

Antenna
-
Impedance
50/75 Ω
Other
-

Electrical

Power requirements
External high-voltage power supply
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
380 × 163 × 335 mm (14.96 × 6.42 × 13.19 in)
Weight
8.50 kg (18.8 lbs)
Form factor
Base Station
Manufactured
Between 19xx and 19xx

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
2919
MPN
HEATHKIT-HW-000101

Manuals, diagrams and brochures

Heathkit Hw-101 Manual PDF - 18.01 MB, submitted by EE Ham
