This transceiver is wideband, using twice (30 kHz) the bandwidth compared to the more traditional 15 kHz used for decades on VHF/UHF ham bands. The audio quality is probably amazing between two equal units.

General characteristics

HAM bands
70cm
Frequency stability
±0.001% @ -10 to +60°C (14 to 140°F)
Tuning steps
20 kHz
Memories
4 channels in 1 bank(s)

Receiver

RX-range
432-439.8 MHz
Modulations
FM
Sensitivity
0.6 µV (20 dB noise quieting)
Selectivity
30 kHz (-6 dB) / 60 kHz (-60 dB)
Filters
?
Receiver system
Double conversion superheterodyne
IF-frequencies
1st: 21.4 MHz
2nd: 455 kHz
Image rejection
?
Audio output
2 W at 10% distortion / 8 ohm

Transmitter

TX-range
432-439.8 MHz
Modulations
FM
RF-output
High: 10 W, Low: 1 W

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
13.8V DC ±15%
Current drain RX
450-630 mA
TX
1.6-3.5 A

Physical

Dimensions (w×h×d)
156 × 58 × 228 mm (6.14 × 2.28 × 8.98 in)
Weight
2.20 kg (4.9 lbs)
Form factor
Mobile
Manufactured
Between 19xx and 19xx in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
Detachable front panel
Accessories
-
RigReference ID
3077
MPN
ICOM-IC-000370
