DSP (UT-106) option.

General characteristics

HAM bands
2m  70cm
Frequency stability
?
Tuning steps
?
Memories
212 channels in 1 bank(s)

Receiver

RX-range
136-174 / 420-480 MHz
1240-1320 MHz (with UX-910 option)
Modulations
FM   N-FM   CW   SSB
Sensitivity
FM: <0.18 µV (12 dB SINAD)
SSB/CW: <0.11 µV (10 dB S/N)
Selectivity
FM: 15 kHz (-6 dB), 30 kHz (-60 dB)
FM-N: 6 kHz (-6 dB), 18 kHz (-60 dB)
SSB/CW: 2.3 kHz (-6 dB), 4.2 kHz (-60 dB)
CW-N: 0.5 kHz (-6 kHz), 1.34 kHz (-60 dB)
Filters
?
Receiver system
Single- double- or triple conversion superheterodyne, depending on band and mode IF frequency matrix
IF-frequencies
?
Image rejection
2m/70cm: >60 dB 23cm: >50 dB
Audio output
?

Transmitter

TX-range
144-146 / 430-440 MHz (Europe)
144-148 / 440-450 MHz (USA)
1240-1300 MHz/10 W (with UX-910 option)
Modulations
FM   N-FM   CW   SSB
RF-output
5-100 / 5-75 W, 1-10 W on 23cm (with UX-910 option)

Connections

Antenna
N-type
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC +/-15%
Current drain RX
Max 3.5 A (with UX-910)
TX
Max 23 A

Physical

Dimensions (w×h×d)
241 × 94 × 239 mm (9.49 × 3.70 × 9.41 in)
Weight
4.50 kg (9.9 lbs) without UX-910
Form factor
Base Station
Manufactured
Between 2000 and 200x in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
Dual 9K6 packet ports and built-in keyer. Twin RX
Accessories
-
RigReference ID
3181
MPN
ICOM-IC-000910H

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used ICOM IC-910H. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the ICOM IC-910H is around:

  • EUR 272.00 ~ EUR 181.00
  • USD 117.00 ~ USD 405.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2020 USD 425.00 Used / Okay MJL
2010 EUR 1129.00 New / Good thiecom.de
2010 EUR 1698.00 New / Good thiecom.de
2009 USD 900.00 Used / Good N9SJA
2006 USD 1300.00 New / Mint NT7J
