General characteristics

HAM bands
2m
Frequency stability
?
Tuning steps
5 / 10 (and 25?) kHz
Memories
5 channels in 1 bank(s)

Receiver

RX-range
144.0-147.995 MHz
(extended range 143.900-148.995 MHz)
Modulations
FM
Sensitivity
≤ 0.5 µV for 30 dB S/N
≤ 0.25 µV for 12 dB SINAD
Selectivity
12 kHz @ -6 dB / 25 kHz @ -60 dB
Filters
?
Receiver system
Double conversion superheterodyne
IF-frequencies
1st: 10.7 MHz
2nd: 455 kHz
Image rejection
?
Audio output
2 W into 8 ohms @ 10% THD

Transmitter

TX-range
144.0-147.995 MHz
(extended range 143.900-148.995 MHz)
Modulations
FM
RF-output
5 / 25 W

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
13.8 V DC
Current drain RX
400 mA
TX
5.5 A max

Physical

Dimensions (w×h×d)
147 × 51 × 198 mm (5.79 × 2.01 × 7.80 in)
Weight
1.50 kg (3.3 lbs)
Form factor
Mobile
Manufactured
Between 1981 and 19xx in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
3461
MPN
KENWOOD-TR-007730

Manuals, diagrams and brochures

Kenwood TR-7730 Instruction Manual PDF - 1.29 MB, submitted by RigReference
TR-7730 PDF - 28.14 MB, submitted by Berend

Upload relevant documents

Reviews & stories

Rating Title Submitted
Great durability! 8 years ago by walban2

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Kenwood TR-7730. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

These estimates are based on the following prices:

Year Historic price Condition Submitted by
