RadioShack / Realistic Pro-2066

Mobile VHF/UHF Scanner / receiver

Add a review Add to my shack


Login or Register to upload images

Find RadioShack / Realistic Pro-2066 rigs and spare parts on eBay Find the RadioShack / Realistic Pro-2066 on Amazon
We receive a small fee if you buy through these links, which helps support this site. Thank you!

1990's trunking radio scanner, supports Motorola I/II/III.

General characteristics

HAM bands
11m (CB)  6m  2m  70cm  33cm
Frequency stability
?
Tuning steps
5 / 12.5 kHz
Memories
150 channels in 5 bank(s) @ 50 channels/second

Receiver

RX-range
26.965-27.405 / 29-54 / 108-174 / 406-512 / 806-956 MHz
Modulations
AM   FM
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
Triple conversion superheterodyne
IF-frequencies
1st: 380.7 MHz
2nd: 10.85 MHz
3rd: 450 kHz
Image rejection
?
Audio output
?

Connections

Antenna
BNC
Impedance
50Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
?
TX
-

Physical

Dimensions (w×h×d)
180 × 50 × 204 mm (7.09 × 1.97 × 8.03 in)
Weight
1.03 kg (2.3 lbs)
Form factor
Mobile
Manufactured
Between 199x and 199x in USA

Other features

Usage
Amateur / Ham radio operators
Features + options
Trunking (800 Motorola I/II/III (1 trunking bank at a time)
5 list, 10 IDs, 50 per bank; 250 IDs total
ID delay
5 priority channels
9 service search bands
5 monitor memories
Direct search
Data skip
Accessories
-
RigReference ID
3792
MPN
20-195
