General characteristics

HAM bands
160m  80m  60m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  11m (CB)  10m
Frequency stability
?
Tuning steps
0.1 kHz
Memories
None

Receiver

RX-range
0.01-30 MHz + FM broadcast band
Modulations
AM   CW   USB   LSB
Sensitivity
AM < 1 µV
SSB < 0,3 µV
Selectivity
AM
10 kHz (-6 dB), 16 kHz (-60 dB)
4,4 (-6 dB), 8 kHz (-60 dB)
SSB
2,0 (-6 dB), 3,4 kHz (-60 dB)
Filters
?
Receiver system
Double conversion superheterodyne
IF-frequencies
1st: 55.845 MHz
2nd: 455 kHz
Image rejection
?
Audio output
?

Connections

Antenna
Built-in sweep
Impedance
?
Other
-

Electrical

Power requirements
12 V DC external, 8 x R20 + 2 x R6 batteries or mains
Current drain RX
?
TX
-

Physical

Dimensions (w×h×d)
254 × 102 × 335 mm (10.00 × 4.02 × 13.19 in)
Weight
7.71 kg (17.0 lbs)
Form factor
Base Station
Manufactured
Between 1981 and 1986 in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
S/Battery-Meter
Record Jack
Pre-selector
NB
Dial Lamp
Dial Lamp Switch
Carry Handle
Muting
RF Gain
Accessories
-
RigReference ID
4003
MPN
SONY-CRF-000001

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Sony CRF-1. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Sony CRF-1 is around:

  • USD 955.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2020 USD 1000.00 Used / Good dxace1
