The WinRadio WR-1550e is a medium-range external receiver similar to its popular predecessor WR-1500e with improved dynamic range, spurious signal rejection and selectivity. The frequency range is 150 kHz to 1.5 GHz (the US version excludes cellular frequencies 825-849 and 869-894 MHz).

General characteristics

HAM bands
?
Frequency stability
10 ppm (0 to 60° C)
Tuning steps
1 Hz / 0.01 kHz
Memories
?

Receiver

RX-range
0.15-1500 MHz
Modulations
AM   N-FM   W-FM   USB   LSB
Sensitivity
AM/SSB/CW: 10dB S/N
FM-N/FM-W: 12dB SINAD

Mode 0.15-1.5 MHz 1.5-30 MHz 30-1000 MHz 1-1.5 GHz
AM 25µV 1µV 1µV 1.9µV
SSB 0.9µV 0.3µV 0.3µV 0.4µV
FM N 0.4µV 0.4µV 0.4µV 0.4µV
FM W - - 1.0µV 1.0µV
Selectivity
SSB/CW 2.5 kHz @ 6dB
AM 6 kHz @ 6dB
FM-N 15 kHz @ 6dB
FM-W 230 kHz @ 6dB
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
65dB
Audio output
0.2W (8 ohm load)

Connections

Antenna
BNC
Impedance
50 Ω
Other
-

Electrical

Power requirements
?
Current drain RX
?
TX
-

Physical

Dimensions (w×h×d)
?
Weight
?
Form factor
Headless
Manufactured
Between 199x and 200x

Other features

Usage
Amateur / Ham radio operators
Features + options
RS-232 computer interface
Accessories
-
RigReference ID
4672
MPN
WINRADIO-WR-001550E

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used WiNRADiO WR-1550e. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

These estimates are based on the following prices:

Year Historic price Condition Submitted by
