NB/ANL. Repeater offset. Dimmer. Scanning. CTCSS option.

General characteristics

HAM bands
12m (WARC)  11m (CB)  10m
Frequency stability
0.001%
Tuning steps
0.1 / 1 / 10 / 100 / 1000 kHz
Memories
None

Receiver

RX-range
24-32 MHz
Modulations
AM   FM   CW   SSB
Sensitivity
AM / CW: 0.5 µV for 10 dB SINAD
FM: 0.25 µV for 12 dB SINAD
SSB: 0.15 µV for 10 dB SINAD
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
65 dB
Audio output
2.5 Watts @ 10% THD into 8 Ohm

Transmitter

TX-range
24-32 MHz
Modulations
AM   FM   CW   SSB
RF-output
AM/FM/CW: 50 W, SSB: 150 W PEP

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
13.8 V DC
Current drain RX
?
TX
18 A max

Physical

Dimensions (w×h×d)
178 × 98 × 23 mm (7.01 × 3.86 × 0.91 in)
Weight
3.40 kg (7.5 lbs)
Form factor
Mobile
Manufactured
Between 200x and 200x

Other features

Usage
Citizen Band (27Mc)
Features + options
-
Accessories
-
RigReference ID
4910
MPN
RANGER-RCI-002970DX

Manuals, diagrams and brochures

Ranger RCI-2950DX / 2970DX Service Manual PDF - 2.80 MB, submitted by RigReference
