The ICOM IC-732M is similar to the ICOM IC-732 in every aspect except output power.

General characteristics

HAM bands
160m  80m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  10m
Frequency stability
?
Tuning steps
?
Memories
10 channels in 1 bank(s)

Receiver

RX-range
0.5-29.995 MHz
Modulations
AM   FM   CW   SSB
Sensitivity
SSB/CW
1.8-29.995 MHz: 0.16 µV (10 dB S/N)
AM
0.5-1.8 MHz: 13.0 µV (10 dB S/N)
1.8-29.995 MHz: 2.0 µV (10 dB S/N)
FM
28.0-29.7 MHz: 0.5 µV (12 dB SINAD)
Selectivity
SSB/CW: 2.1 kHz (-6 dB), 4.0 kHz (-60 dB)
AM: 6 kHz (-6 dB), 20 kHz (-60 dB)
FM: 12 kHz (-6 dB), 32 kHz (-60 dB)
Filters
?
Receiver system
Triple conversion superheterodyne
IF-frequencies
1st: 69 MHz
2nd: 9 MHz
3rd: 455 kHz
Image rejection
> 70 dB
Audio output
2.6 W @ 8 ohm

Transmitter

TX-range
10-160 m + WARC
Modulations
AM   FM   CW   SSB
RF-output
SSB/CW/FM: 2.5-25 W, AM: 2.5-10 W

Connections

Antenna
SO-239
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
4 A
TX
5 A max

Physical

Dimensions (w×h×d)
330 × 111 × 285 mm (12.99 × 4.37 × 11.22 in)
Weight
8.05 kg (17.8 lbs)
Form factor
Base Station
Manufactured
Between 1992 and 199x in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
5129
MPN
ICOM-IC-000732M

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used ICOM IC-732M. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

These estimates are based on the following prices:
